Blue High Speed Alternator High Voltage Generator 30kw 37.5kva 60hz

Blue High Speed Alternator High Voltage Generator 30kw 37.5kva 60hz

  • Blue High Speed Alternator High Voltage Generator 30kw 37.5kva 60hz
Blue High Speed Alternator High Voltage Generator 30kw 37.5kva 60hz
รายละเอียดสินค้า:
สถานที่กำเนิด: Wuxi,China
ชื่อแบรนด์: Werna
ได้รับการรับรอง: CE,ISO9001,SASO
หมายเลขรุ่น: WR184G
การชำระเงิน:
จำนวนสั่งซื้อขั้นต่ำ: 5pcs
ราคา: negotiation
รายละเอียดการบรรจุ: Plywood
เวลาการส่งมอบ: Within 10 days
เงื่อนไขการชำระเงิน: T/T
สามารถในการผลิต: 1000units/month
ติดต่อ
รายละเอียดสินค้า
Insulation Class: Class H Rated Voltage: 190-454v
Protection: IP 22 Packing: Plywood
Wire: 100 % copper wire THF: < 2 %
แสงสูง:

3 phase portable generator

,

three phase alternator

Blue High Speed Three Phase AC Generator / Alternator 30kw / 37.5kva 60hz


Quick detail:

Name

ALTERNATOR

Brand Name

WERNA

Color

According to the international standard color card

Feature

AC brushless synchronous excitation alternator

Power

30KW

Certificate

CE,ISO9001,SASO


Specication:

manufacture

Wuxi City ,Jiangsu Prov ,China making alternators

Output type

AC Three Phase Brushless generator

Terminal

12 / 6 Wire

Rated Voltage

208V~480V

Frequency

60Hz

Speed

1800RPM

Mounting Dimension

Stamford Type

Winding  pitch

2/3 pitch

Excitation

Brushless, self-excited, synchro

Insulation Class

H

 Technical Datas

Werna Type 3Phase 60Hz 1800rpm Shaft length Copper total weight Core length
  208V~480V
  KVA KW mm kgs mm
WR164A 10.2 8.2 373.16 9.98 65
WR164B 13.8 11 373.16 11.18 80
WR164C 16.9 13.5 400.16 11.6 100
WR164D 20.2 16 400.16 11.88 115
WR184E 28.8 23 440.16 14.72 150
WR184F 34.4 27.5 530.16 16.2 190
WR184G 37.5 30 530.16 17.8 230
WR184H 46.9 37.5 673.3 19.21 255
WR184J 50 40 673.3 20.48 285

Description:
with long experience in manufacturing alternator / ac generator.
 Alternator Power Ranging 6.5 --1200KW
for prime or standby use, more than 50 different models, with 50Hz or 60Hz frequency, Single bearing or Double bearing, brushless, Self-excited. Abounds with almost every model in stock.

 Frequency And Voltage
50Hz or 60Hz as per customer’s request. Voltage from 380 ~ 690V, 190V~345V, 220~400V, serial star, parralle star and serial delta connection are available, All three-phase generators are 12-lead reconnectable, providing voltage and phase flexibility.

Insulation and Protection
Insulation: H, Protection: IP23
 IP23 is for optional but the rated power will decrease 5%.

 Voltage Regulators
The model we use including: MX321, MX341, AS440, SX440, SX460, etc.

 Winding
All generator stators are wound to 2/3 pitch.

Why to choose Werna Alternator/generator?
1. 100% copper winding wire
2. In stock and fast delivery
3. Two year warranty
4. Best quality and competitive price
5. Two-time vacuum impregnation dipping
6. powerful quality control team
7. CE,ISO9001
8. Good after-sale service
Blue High Speed Alternator High Voltage Generator 30kw 37.5kva 60hz 0Blue High Speed Alternator High Voltage Generator 30kw 37.5kva 60hz 1
